SSC308QE AI Vision Board

Overview

Highly integrated ISP SoC platform on SigmaStar SSC308QE (board ID SHT-SSC308QE-V1.0) for ~8MP smart vision and HD AI IPC. Single-chip ISP, H.265/H.264 codec, IPU / IVE acceleration, and memory—for fast security and smart-home camera mass production.

Compute & main controller

Main SoC	SigmaStar SSC308QE
CPU	Dual-core ARM Cortex-A32 up to ~1GHz; dedicated Cortex-M4 up to ~200MHz
Memory	Built-in 2Gb DDR3L
AI capability	Built-in IPU + IVE; human / face, intrusion, line-crossing analytics
Typical use cases	HD AI IPC, smart home cameras, light commercial vision terminals

Imaging & encoding

ISP	High-performance ISP: NR / LSC / LDC, AWB / AE / AF, WDR/HDR, defect correction, color enhancement, and more
Sensor input	Up to ~8MP (3840×2160); MIPI / CSI at solution level
Video encode	H.265 / H.264; typical 4K@30fps + 720p@30fps dual stream
Still capture	JPEG / MJPEG (module and firmware dependent)
Camera interface	On-board FFC / FPC connector

Connectivity & peripherals

Network	Ethernet MAC + 10/100Mbps PHY (solution level)
Storage	SDIO / SD / eMMC expansion (board design dependent)
USB	Micro-USB (power / debug)
Package reference	Typical QFN128 high-integration package on chip side

Interfaces & mechanical

Board ID / revision	SHT-SSC308QE-V1.0
Expansion connectors	Multiple white multi-pin headers (power, I/O, peripherals)
Mechanical	Compact square board, four mounting holes—for in-device mounting

Typical applications

• HD / 4K AI IPC
• Smart home and light commercial security cameras
• Vision terminals needing on-device human / face analytics

Note: Encode frame rates, AI features, and interface specs follow SigmaStar SSC308QE public documentation and your BOM / firmware configuration; mass-production parameters are confirmed in pilot builds.
